TPD6V8LP
Maximum Ratings @T A = 25°C unless otherwise specified
Characteristic
Peak Pulse Power (tp = 8 x 20 μ s) (Note 4) (See figure 6)
Forward Voltage (Note 5) @ I F = 10mA
Peak Pulse Current (tp = 8 x 20 μ s) (Note 4) (See figure 6)
Human Body Model
Symbol
P pk
V F
I pp
Value
85
0.9
4.5
8
Unit
W
V
A
kV
ESD Rating
Machine Model
IEC61000-4-2 Air Discharge
IEC61000-4-2 Contact Discharge
V pp
400
±25
±8
V
kV
kV
Thermal Characteristics
Characteristic
Power Dissipation (Note 4)
Thermal Resistance, Junction to Ambient Air (Note 4)
Operating and Storage Temperature Range
Symbol
P D
R θ JA
T J, T STG
Value
250
500
-65 to +150
Unit
mW
° C/W
° C
Electrical Characteristics @T A = 25°C unless otherwise specified
Reverse Standoff Voltage
Characteristic
Symbol
V RWM
Value
5
Unit
V
Breakdown Voltage @ I T = 5mA (Note 5)
Minimum
Maximum
V BR
6.4
7.2
V
Maximum Reverse Leakage @ V RWM (Note 5)
Maximum Clamping Voltage @ I pp = 4.5A (tp = 8x20 μ s) (See figure 6)
Typical Total Capacitance (V R = 0V, f = 1MHz)
I R
V C
C T
0.5
19
65
μ A
V
pF
Notes:
4. Part mounted on FR-4 PC board with recommended pad layout, as per http://www.diodes.com.
5. Short duration pulse test used to minimize self-heating effect.
300
Note 4
250
200
150
100
50
0
0
25 50 75 100 125
150
0
0.3
0.6
0.9 1.2 1.5
T A , AMBIENT TEMPERATURE (°C)
Fig. 1 Power Derating Curve
V F , INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 2 Typical Forward Characteristics
TPD6V8LP
Document number: DS30914 Rev. 8 - 2
2 of 4
www.diodes.com
November 2011
? Diodes Incorporated
